Dear All, I'm facing a problem with my Windows 7 PC. My configuration is: - SSD OCZ Agility 128 GB (System) - HDD 1TB Caviar black - HDD 3TB Caviar Green I bought a new SSD where I want to migrate the system is a 480 GB Sandisk drive.

I've used EZ Gig IV SanDisk to clone the OCZ onto the Sandisk Drive. After I switched off the PC and selected my Sandisk as boot drive (OCZ not installed). I won't start and the PC comes up with the first image. I went into the bios and disable all the HDD (the sandisk was set as boot drive) and it comes UP with the second Image.

I tried to boot only from my OCZ (without enabling the HDDS) and no luck again with the second Image. So I tried boot with my OCZ and the black and the system boots up. I tried another way again from the BIOS I set the Sandisk as first boot option and the black as second the other drives are not set as boot and the system boots up (the C drive still the OCZ) Can someone help me finding the solution to my problem? I'm getting crazy. Thank you https://drive.google.com/folderview?id=0BzgnvXJU8XHTMU5RUVFySDFtZjA&usp=sharing. Do not Clone, instead use create an Image Backup and restore the backup to your new SSD.

Note that when restoring the image look for an option that instructs the Image Recovery / Restore software that you are restoring to an SSD (This creates the proper drive offset required by an SSD.) Also check to see which drive is marked as the System / Active partition. It should by your 128GB OCZ (150MB System, Reserved partition located at the front of the SSD. If one of your Western Digital hard drives is marked as the system / active partition let me know and I'll show you what to do.

=================== Image Backup Software =================== How to create an Image Backup to a USB Flash Drive How to move windows 7 to a new larger hard drive EaseUS: Todo Backup Home V9.0 User friendly interface simplifies the backup process. Free version: Version comparison chart: Includes: Incremental backup, Disk/partition clone User's Guide: Note: Install Todo and then create an 'Emergency Disk' (WinPE option is the better of the two choices) before you start creating your first image backup. Version 9.0 supports XP, Vista, Windows 7, 8 / 8.1 and Windows 10 Acronis: True Image 2016 Has a 30 day trial version available, trial Key sent to your Email Address. User interface has become more complex and less obvious, be prepared to read the user's guide before you start. Pay special attention to the 'Options' and don't exclude the 'System Volume Information' folder from the backup.

Note: Cloning and drive initialization (creating a MBR) are not supported in the trial version. Image Backups and restores are fully functional.

For the trial version, recovery / restore image is available only when booting from an Acronis Bootable Media CD. Hi Alessio, I notice that you are trying to clone your system by using EZ Gig IV, right?

I agree with J W Stuart, it is not suggested that to use 3rd party App to clone your system. Microsoft do not provide support for 3rd party software. Based on your situation, we could try to create an Image Backup then restore the backup to your new SSD.

Here is a link for reference of the detailed steps: Best regards. NOTE: This response contains a reference to a third party World Wide Web site. Microsoft is providing this information as a convenience to you. Microsoft does not control these sites and has not tested any software or information found on these sites. Please remember to mark the replies as answers if they help, and unmark the answers if they provide no help. If you have feedback for TechNet Support, contact tnmff@microsoft.com. Sorry but the images you posted are too small to read the error message, but it appears to be something different than what I described in my Wiki article I posted earlier.

Therefore I suggest you start over. Use the free version of EaseUS Todo Backup: Its the easiest to use a there is not an overly complicated user interface. User's Guide: Read the User's Guide but here are some quick tips: Page 22 Backup type There are three backup types: Full, Incremental or Differential. Each of them can be specified to a created schedule and decide how the schedule goes. Discreet 3ds Max 6 Free Download. Download Camfrog Pro Untuk Pcc. You want to create a Disk and Partition backup (Page 9) and only place a check mark to select the old SSD to include it the backup (No other drives should be slected).

Also select the 'Full' backup, no schedule (one time backup). Do not choose the sector by sector backup option, a standard disk backup is the normal backup method.

Click Tools - Create emergency disk. In this step, you have a choice to create a WinPE or Linux emergency disk. The best option is to create a WinPE emergency disk as it is more likely to be compatible with an external USB drive which is where you should create and Store the Image Backup.

After you create the backup, remove the old SSD and connect the new SSD. Restore the Image Backup by booting from the Emergency Disk you created and browse / navigate to the external USB drive.

Locate the image Backup file, select it and the restore to the new SSD. Remember to select / place a check mark in the 'Optimized for SSD' option (Page 34). Never be afraid to ask. This forum has some of the best people in the world available to help. Hello J W, I'm getting crazy with this. I've tried no luck.

I tried the Image backup as in the turorial when I went in the restoring I receive a strange configuration as in the picture. What method you think is the one to follow for the System Image Backup? (Image called Error in the same drive folder) I'm OK you you may want to contact me and try to take a look in remote control to my PC. So far: My needs are to copy my actual windows (that has the system reserved partition on the Caviar Black 1TB drive and the acrual system on the OCZ) into my new sandisk 480 GB for space reasons. Thank you again, my emailif you want to contact me is ale.minna@gmail.com.

No you don't want to perform a 'System Image' backup, you want to perform a Disk and Partition backup. The only disk / Partition you should select is the OCZ drive and do not include the System partition on the Caviar drive (keep them disconnected). You will then restore the OCZ partition you backed up to the new SSD (with the caviar drives disconnected. Finally you will use method #2 to create a new BCD store / System partition which will now be part of the Windows partition. Use Method #2 in the Wiki article: Method 2 - BCD (Boot Configuration Data) store is corrupt or missing (In your case it is missing) Do this with all the Caviar drives disconnected. J W Stuart: Never be afraid to ask. This forum has some of the best people in the world available to help.

This is because windows new boot mode UEFI holds all this in a dos file the keeps any and all drives installed whether you understand this and when you install the MBR to the first drive u install in the computer this file records this as the drive to boot from only there is a command in dos that you can use to fix this that's why if you try booting from any other drive that windows was preinstalled on it will not boot from it on your computer till you delete the last drive from that file search for dos commands for windows 8 for fixing the MBR file.
